iBeacon for Smart Hospital Management

Introduction to iBeacon in Healthcare

iBeacon technology is revolutionizing hospital operations by enabling real-time location services (RTLS), patient flow optimization, and asset tracking. These low-energy devices create an intelligent healthcare ecosystem that improves efficiency while enhancing patient care.

iBeacon Card Customization Options:

1. Appearance & Design

Graphics/Logo: Custom artwork, company logos, or personal photos.

Text: Personalized text such as names, contact details, or promotional messages.

Material & Shape: Choice of plastic, metal, or other materials; standard credit card size or custom shapes (e.g., keychain tags).

2. iBeacon Technical Parameters

UUID/Major/Minor Configuration:

UUID: Unique identifier for your organization or application.

Major & Minor: Sub-identifiers for specific locations (e.g., store sections, event zones).

Signal Strength (RSSI): Adjusta broadcast range (proximity-based triggers).

Broadcast Interval: Optimize battery life or responsiveness.

3. Functionality & Interaction

Trigger Actions:

Push notifications (greetings, promotions).

Auto-open URLs, apps, or navigation maps.

Track user interactions for analytics.

Multi-Stage Triggers: Different actions based on distance (e.g., "Welcome" at 10m, "Special Offer" at 2m).

4. Data & Security

Dynamic Content: Some cards allow remote updates via cloud platforms.

Encryption & Access Control: Restrict beacon visibility to authorized apps/users.

5. Use Case Customization

Corporate: Employee badges (access control + attendance tracking).

Retail/Events: Proximity marketing, interactive exhibits.

Personal: Smart business cards (auto-share contact info), anti-loss tags.

IoT Integration: Smart home triggers (e.g., unlock doors when detected).

FAQs：

Q1: What is an iBeacon real-time location card?
A: A credit card-sized Bluetooth Low Energy (BLE) device that continuously broadcasts a unique identifier signal. When carried by a person or attached to an asset, nearby receivers pick up the signal and report the card's location in real time to your management system.

Q2: How does the iBeacon card work?
A: The card broadcasts BLE signals at regular intervals containing a UUID, Major, and Minor identifier. Gateways or receivers installed throughout your site detect these signals and calculate the card's approximate position based on signal strength (RSSI). Location data is then sent to your backend platform for real-time visibility.

Q3: What is the difference between iBeacon and Eddystone?
A: Both are BLE broadcasting protocols. iBeacon is Apple's specification, widely used in enterprise and retail deployments; Eddystone is Google's open standard, which also supports broadcasting URLs and sensor data. We support both — the choice depends on your existing infrastructure and software platform.

Q4: What is the broadcast range?
A: Configurable, typically 1–70 meters depending on the environment and signal power setting. Short range (1–3m) suits desk-level presence detection; longer range (10–70m) suits room- or zone-level tracking across large floor areas or open campuses.

Q5: How accurate is the location tracking?
A: Accuracy depends on gateway density and site layout — typically room-level to zone-level (3–10m). It is not GPS-level pinpoint accuracy, but sufficient for "which area, floor, or zone" tracking in enterprise and campus environments. Denser gateway deployment improves accuracy.

Q6: What powers the card, and how long does the battery last?
A: The card is equipped with a built-in lithium battery. Low power Bluetooth itself has extremely low power consumption. Under standard broadcast frequency, a 100mAh battery can last for 1-3 months on a single charge; Extending the broadcast interval and increasing the battery capacity can significantly improve the battery life, while shortening the interval can update the position faster.

Q7: Can the broadcast interval be configured?
A: Yes. Broadcast interval is adjustable — a shorter interval (e.g., 100ms) gives faster location updates at the cost of battery life; a longer interval (e.g., 1000ms) preserves battery at the cost of update frequency. We configure this to match your deployment requirements.

Q8: What is the card form factor?
A: Standard credit card size (85.6 × 54 mm), designed to fit in a badge holder, ID sleeve, or wallet. Custom form factors (key fob, wristband, tag) are available for OEM orders.

Q9: Does the card also support NFC?
A: Yes, as an option. Cards can be configured with both BLE (for location tracking) and NFC/RFID (for door access, attendance tap-in, or data read/write), enabling dual-function deployment with a single card.

Q10: What infrastructure do we need to deploy?
A: BLE gateways or receivers installed throughout the coverage area — one per 10–15 meters for higher accuracy, or wider spacing for zone-level tracking. The card itself requires no setup on the site side beyond carrying it. Gateway hardware is not supplied by us but we can recommend compatible options based on your system.

Q11: Can the card integrate with our existing workforce or asset management system?
A: Yes, at the data layer. The cards and gateways provide location data; your platform consumes it via API or SDK. We provide protocol documentation to support integration with your existing system — share your stack and we can confirm compatibility.

Q12: What industries use iBeacon location cards?
A: Enterprise workforce management, manufacturing, warehousing and logistics, healthcare (staff and equipment tracking), education (campus safety and attendance), retail (staff and asset management), and hospitality.

Q13: Do you offer OEM and ODM services?
A: Yes. We provide comprehensive OEM/ODM hardware customization services for enterprise and system integrator partners, covering functions, materials, appearance and more.
